Non Contact Shaft Measuring Machine Suppliers in Chennai

Non Contact Shaft Measuring Machine Suppliers In Chennai

Non Contact Shaft Measuring Machine Suppliers In Chennai – Kosaka Calibration was established to design and deliver measuring instruments of best quality Non Contact Shaft Measuring Machine Suppliers in Chennai. As a part of a Corporate Group, Kosaka Calibration, we are effectively sufficing to the requirements of clients pertaining to Snap Gauge, Slip Gauge Blocks, Caliper Checker, Measuring Pin Set, Adjustable Snap Gauge, Tool Presetting Machine and more.

Throughout the years, we have strengthened our position as a manufacturer and supplier by focusing on product innovation, quality and development. This has helped us achieve technological excellence and become a pioneer in the field of metrology.

Requirements of Non Contact Shaft Measuring Machines are fulfilled within the stipulated time

We have a sophisticated infrastructure which is staffed with talented software developers and engineers. They work in sync with each other to ensure our clients requirements are fulfilled within the stipulated time frame.

Shaft Measuring Machine is helpful for measuring different kinds of limit gauges, measuring instruments, standards, and thread, spline, etc. It is employed for things whose geometric relationships are more important than absolute coordinates. In addition to this, they said product places a lot of importance on sphere diameter measurements in Non Contact Shaft Measuring Machine. Typically, a comparative approach or direct method employing a 1D linear measuring device is used to measure diameter.

Non Contact Shaft measuring machine is a device with the full range of mechanical calibration. It also observes the abbes principle over the entire measuring range, a constant measuring force is maintained.

Some Specification of Non Contact Shaft Measuring Machine:

Shaft Measuring Range – External : 0-600 mm
Non Contact Measuring Range – Internal : 3-450 mm with optical accessories
Instrument Uncertainty : 0.7 +L/1000 micrometer (0.4 +L/1000 micrometer) – On request
Resolution : 0.1 micrometer / 0.01 micrometer with optical accessories
Repeatability : 0.3 mircometer at +/- 2 sigma (0.2 micrometer at +/- 2 sigma)

Non-contact Shaft is presented for detecting torque of a rotating stepped shaft which is frequently employed in power transmission system. This sensor doesn’t require cutting or lengthening the rotating shaft. Torque value is obtained by using two magnetic sensors to sense magnetic field intensity of two permanent rubber magnets fixed at the outer surface of the shaft.

The phase difference between these two induction signals is used to determine torque of the stepped shaft. A real-time algorithm based on lab view is employed to obtain the measured torque value. The present work has demonstrated that non-contact torque measurement for rotating stepped shaft by monitoring magnetic field is feasible. It seems like that further development will result in low-cost torque sensor. It is hoped that this kind of sensor can lead to a new development direction of torque sensor for rotating shaft.
